FRP Vertical Walkway – 10.98 Meter is a premium rooftop access solution designed to provide safe and secure movement for maintenance personnel on metal roof solar installations. Manufactured using high-strength Fiber Reinforced Plastic (FRP) grating, the walkway offers exceptional resistance to corrosion, UV rays, fire, and harsh weather conditions while remaining lightweight and easy to install.
The kit includes Short Rack PT-41 supports, FRP gratings, stainless steel fasteners, M Clamps, EPDM sealing tape, C-Clips, spring nuts, and pop rivets, ensuring a complete installation solution. The anti-slip FRP surface minimizes the risk of slips and falls, making it ideal for regular inspection and maintenance of rooftop solar plants without damaging the roof sheets.
Designed for long service life with minimal maintenance, the SRPL FRP Vertical Walkway is suitable for commercial, industrial, and warehouse rooftops.
| Specification | Details |
|---|---|
| Product Name | FRP Vertical Walkway – 10.98 Meter Kit |
| Walkway Length | 10.98 Meter |
| Walkway Width | 310 mm |
| Grating Size | FRP Grating 3.66 m × 310 mm |
| No. of FRP Gratings | 3 Nos. |
| Support Type | Short Rack PT-41 L350 |
| Support Material | Galvanized Steel |
| Grating Material | Fiber Reinforced Plastic (FRP) |
| Fastener Material | SS304 / A2 Stainless Steel |
| Mounting Type | Metal Roof Installation |
| Installation Method | Penetrative / Non-Penetrative |
| Surface Finish | Anti-Slip FRP Grating |
| Corrosion Resistance | Excellent |
| UV Resistance | Yes |
| Fire Resistance | Yes |
| Weather Resistance | Suitable for Outdoor Use |
| Application | Solar Rooftop Maintenance Walkway |
| Warranty | 10 Years* |
Key Features
Product Demo Video:
▶ Watch Product Demo on YouTube
| Product Description | Quantity |
|---|---|
| Short Rack PT-41 L350 | 12 Nos. |
| M Clamps M8 | 24 Nos. |
| C-Clip (M6 Hole) | 4 Nos. |
| Allen Bolt M8 × 25 SS304/A2 | 24 Nos. |
| Allen Bolt M6 × 35 SS304/A2 | 4 Nos. |
| Hex Nut M6 SS304/A2 | 4 Nos. |
| Plain Washer M6 SS304/A2 | 8 Nos. |
| Plain Washer M8 SS304/A2 | 24 Nos. |
| Spring Washer M8 SS304/A2 | 24 Nos. |
| Pop Rivet 4.8 × 19 Aluminium | 48 Nos. |
| EPDM Tape (3 mm × 40 mm × 5 m) | 0.396 Roll |
| Spring Nut M8 (Coated) Galvanized | 24 Nos. |
| FRP Grating 3.66 m × 310 mm | 3 Nos. |
| Total Components | 203.396 |
It provides a safe anti-slip access path for maintenance personnel on rooftop solar installations.
The kit provides approximately 10.98 meters of FRP walkway.
Yes. FRP is highly resistant to corrosion, chemicals, moisture, and rust.
Yes. It is specially designed for metal roof solar projects.
Yes. It is UV resistant, weather resistant, and suitable for long-term outdoor use.
Yes. The FRP grating has an anti-slip surface for enhanced worker safety.
All fasteners are manufactured from SS304/A2 stainless steel for long-lasting durability.
Yes. The kit is supplied with all required mounting hardware for easy and fast installation.
FRP requires very little maintenance and provides a long operational life.
The FRP Vertical Walkway Kit comes with a 10-year warranty against manufacturing defects, subject to SRPL warranty terms.
