The FRP Horizontal Walkway (10.98 Meters) is a premium access system specially designed for safe movement and maintenance on rooftop solar power plants. Manufactured using high-strength Fiber Reinforced Plastic (FRP) grating, the walkway offers excellent corrosion resistance, UV protection, fire retardant properties, and superior anti-slip performance for all weather conditions.
The walkway protects metal roofs from foot traffic damage while providing a stable and secure maintenance path for technicians. Suitable for both penetrative and non-penetrative installation methods, it delivers quick installation, lightweight handling, long service life, and virtually maintenance-free performance.
SRPL Group offers FRP walkways in multiple grating heights including 25mm, 30mm, 38mm, and 50mm to meet different load-bearing requirements. The product is ideal for industrial buildings, commercial rooftops, warehouses, factories, and solar installations requiring safe rooftop access.
| Product Name | FRP Horizontal Walkway (10.98 Meters) |
| Walkway Length | 10.98 Meters |
| Walkway Width | 310 mm |
| Grating Length | 3.66 Meter Each |
| No. of FRP Gratings | 3 Nos. |
| Material | Fiber Reinforced Plastic (FRP) |
| Surface Finish | Anti-Slip |
| Installation Type | Horizontal Walkway for Metal Roof |
| Mounting Method | Penetrative / Non-Penetrative |
| Fastener Material | SS304/A2 Stainless Steel |
| Clamp Type | M5 Clamps with C-Clip |
| Weather Resistance | Excellent |
| Corrosion Resistance | Excellent |
| UV Resistance | Yes |
| Fire Retardant | Yes |
| Chemical Resistance | Excellent |
| Load Capacity | Suitable for Rooftop Maintenance Access |
| Application | Solar Rooftops, Industrial Buildings, Commercial Roofs, Warehouses, Factories |
| Maintenance | Maintenance Free |
| Warranty | 10 Years |
Product Demo Video:
▶ Watch Product Demo on YouTube
| Product Description | Quantity |
|---|---|
| M Clamps M5 | 24 Nos. |
| C-Clip (M6 Hole) | 4 Nos. |
| Allen Bolt M6 × 35 SS304/A2 | 4 Nos. |
| Hex Nut M6 SS304/A2 | 4 Nos. |
| Plain Washer M6 SS304/A2 | 8 Nos. |
| Pop Rivet 4.8 × 19 Aluminium | 24 Nos. |
| EPDM Tape (3mm × 40mm × 5m) | 0.12 Roll |
| FRP Grating 3.66m × 310mm | 3 Nos. |
| Total Components | 71.12 |
It provides a safe anti-slip access path for maintenance personnel working on rooftop solar installations.
The kit provides a total walkway length of approximately 10.98 meters.
Yes. The FRP grating is highly resistant to corrosion, chemicals, moisture, and harsh outdoor environments.
Yes. It is UV resistant, weatherproof, fire retardant, and designed for long-term outdoor use.
Yes. The system supports both penetrative and non-penetrative installation methods depending on the roof design.
Yes. It distributes foot traffic safely, reducing direct load on the roof sheet and minimizing roof damage.
SRPL Group offers FRP gratings in 25mm, 30mm, 38mm, and 50mm heights with various load capacities.
The FRP Horizontal Walkway comes with a 10-year warranty under standard installation and operating conditions.
