The Classic Rack – Aluminium is a compact and robust solar mounting solution designed for 2 × 1 panel orientation with a 2-module configuration. Manufactured using high-quality aluminium and stainless-steel hardware, the system provides a durable, lightweight and reliable mounting solution for rooftop solar installations.
The mounting kit includes aluminium leg profiles, clamping plates, support bases, short racks, end and mid clamps, stabilizers and complete SS304/A2 fastening hardware for a secure installation.
| Parameter | Specification |
|---|---|
| Product | Classic Rack – Aluminium |
| Panel Orientation | 2 × 1 |
| Module Count | 2 Modules |
| Primary Material | Aluminium |
| Aluminium Grade | AL 6063-T6 |
| Fastener Material | SS304 / A2 |
| Short Rack | PT-41 L100 |
| End Clamp | Z Type – 30 mm |
| Mid Clamp | U Type – 30 mm, AL 6063-T6 |
| Clamp Spacer | PVC |
| Stabilizer | CU 52 × 20 × 20 × 0.65 mm |
| Description | Total Qty |
|---|---|
| Leg Profile T1-L320 | 3 |
| Leg Profile T1-L680 | 3 |
| Clamping Plate 15D | 6 |
| CL Base Support – L150 mm, AL 6063-T6 | 6 |
| Allen Bolt M8 × 25 SS304/A2 | 6 |
| Allen Bolt M8 × 70 SS304/A2 | 18 |
| Plain Washer M8 SS304/A2 | 42 |
| Hex Nut M8 SS304/A2 | 18 |
| Spring Washer M8 SS304/A2 | 6 |
| Spring Nut M8 – Coated Galvanised | 6 |
| Short Rack PT-41 L100 | 6 |
| End Clamp (Z Type) – 30 mm | 4 |
| Mid Clamp (U Type) – 30 mm, AL 6063-T6 | 2 |
| Clamp Spacer – PVC | 6 |
| Pop Rivet 4.8 × 19 – Aluminium | 72 |
| Stabilizer CU 52 × 20 × 20 × 0.65 L1650 | 3 |
| Stabilizer CU 52 × 20 × 20 × 0.65 L1450 | 4 |
The Classic Rack configuration is designed for 2 solar modules in a 2 × 1 panel orientation.
The system primarily uses aluminium components, including AL 6063-T6 aluminium for specified structural and clamping components.
The kit includes SS304/A2 stainless-steel bolts, nuts and washers, along with coated galvanised spring nuts.
Yes. The kit includes 4 Z-Type 30 mm end clamps and 2 U-Type 30 mm mid clamps.
Yes. Its lightweight aluminium construction and compact configuration make it suitable for appropriate rooftop solar mounting applications, subject to site-specific structural and wind-load requirements.
Yes. The kit includes stabilizers in L1650 mm and L1450 mm lengths to provide additional structural support.
Yes. The kit includes the listed aluminium profiles, racks, clamps, supports, stabilizers, fasteners, washers, nuts, spacers and pop rivets required for the specified configuration.
